High
10kHz shelving control lets you enhance high-frequencies to add sparkle or air or soften the top end to warm up overly aggressive tracks.
Hi-Mid Gain
Used to adjust the amount of mid boost or cut being applied to the signal. Up to 12dB of boost or cut is available.
Hi-Mid Frequency
Lets you sweep the upper mid band between 1kHz to 8kHz to find the optimum center frequency.
Q
Lets you set the width of the mid-range frequency bands. Wider for more musicality or narrower for surgical precision.
Lo-Mid Gain
Used to adjust the amount of mid boost or cut being applied to the signal. Up to 12dB of boost or cut is available.
Lo-Mid Frequency
Lets you sweep the lower mid band between 300Hz to 2.4kHz to find the optimum center frequency.
EQ-In
Turns on the equalizer or acts as a bypass so you may compare the wet post EQ effect with the dry pre-EQ signal.
Omniport
Configured as a TRS in-out connection. This lets you patch to-and-from the insert point of your mixing console using a single ¼” TRS cable.
