XLR Inputs
Glass-filled nylon XLR connectors are tougher than steel, provide 100% isolation. Feature nickel-silver contacts that will not tarnish over time.
XLR Thru
Thru output of XLR inputs with the option of mic or line level transformer isolation.
RJ45 Thru
Parallel connection from XLR outputs used to feed additional Catapult module.
RJ45 Output
Standard Ethernet connection for shielded Cat 5 cable used to send audio to the Catapult RX module.
XLR Output
Glass-filled nylon XLR connectors are tougher than steel, provide 100% isolation. Feature nickel-silver contacts that will not tarnish over time.
XLR Thru
Thru output of XLR inputs with the option of mic or line level transformer isolation.
RJ45 Input
Standard Ethernet connection for shielded Cat 5 cable used to receive audio from Catapult TX module.
RJ45 Thru
Parallel connection from XLR outputs used to feed additional Catapult module.
Ground Lift
Lifts the Cat 5 cable ground path to help eliminate troublesome ground loop noise.
Bumper
Used to protect the Ethernet connectors and ground switch from damage.
Line Transformer
TXL and RXL modules are transformer isolated at the XLR outputs and at the Ethernet THRU connector to provide line level isolation to eliminate hum and buzz.
Mic Transformer
TXM and RXM modules are transformer isolated at the XLR outputs and at the Ethernet THRU connector to create a mic level split for stage and studio use.
Catapult Resources
- Model:
- TX4
- RX4
- TX4M
- RX4M
- TX4L
- RX4L
- Part No:
- R800 8022 00
- R800 8025 00
- R800 8023 00
- R800 8026 00
- R800 8024 00
- R800 8027 00
