KL-8 Specifications

Frequency response: 20Hz to 20kHz +/- 0.5 dB
Dynamic range: Main & Monitor Outputs: 90 dB referred to +28 dBu, 102 dB A-Weighted
Total harmonic distortion: Main & Monitor Outputs: 0.01% (100Hz to 20kHz @ 0 dBu) (-80 dB)
Input Impedance: Analog Inputs 1-4: 14.3 to 20k Ω (input level max / input level min); Auxillary Inputs: 33k Ω
Output Impedance: Auxillary Outputs: 2.2k Ω; Main & Monitor Inputs: 1.1k Ωl Headphone Outputs: 51 Ω
Maximum Input: Analog Inputs 1-4: +18 dBu (+16dBV); Auxillary Inputs: +11dBu
Maximum Output: Auxillary Outputs: +18dBu; Main & Monitor Outputs: +28dBu; Headphone Outputs: 0.4 W into 15 Ω (8.3 VRMS max)
Extras: USB Digital Connection - Bit Depth / Sample Rate: 24bit /192kHz
Size (L x W x D): 19" x 7" x 1.62" (48.26mm x 17.8mm x 4.13mm)
Weight: 6.25lb (2.83kg)
Shipping size (L x W x D): 22” x 10.375” x 4.5” (55.9mm x 26.4mm x 11.4mm)
Shipping weight: 8.9lb (4.04kg)
Power: 100V to 240V, locking 4-pin XLR
Conditions: For use in dry locations only between 5°C and 40°C
Warranty: Radial 3-year, transferable

What do these graphs mean? Learn what to look for and why it matters.

Learn More

KL-8 Resources

Part no: R800 1428 00
